UPE-003
Xinxing
UHMW-PE (Ultra High Molecular Weight Polyethylene) is thermoplastic engineering plastics, which is normally used in the area of marine, transport, coal-mining, machinery, paper-making, textile industry, etc.
Features of UHMWPE Sheets and Components:
· Very low friction coefficient
· High impact strength without breaking or shattering
· High abrasion resistance
· Chemically inert, suitable for nearly all chemicals, including HCL
· Survive in Freezing Conditions from ( -200 Degree C to 80 Degree C )
· Anti-stick properties and self-lubricating materials
Technical data of UHMWPE sheet:
| Project Name | Unit | Test Method | Test Result |
| Density | g/cm3 | ASTM D-1505 | 0.94-0.98 |
| Compressive Strength | Mpa | ASTM D-638 | ≥42 |
| Water Absorption | % | ASTM D-570 | <0.01 |
| Impact Strength | KJ/m2 | ASTM D-256 | ≥140 |
| Heat Distortion Temperature | ºC | ASTM D-648 | 85 |
| Shore Hardness | Shore D | ASTM D-2240 | >40 |
| Friction Coefficient | ASTM D-1894 | 0.11-0.17 |
Parameter of UHMWPE sheet:
| Items | Unit | Data | ASTM Test Method |
| Molecular Weight | billion | 3~9 | D2857 |
| Specific Gravity | g/cm^3 | 0.935~1.0 | D1505 |
| Tensile Strength | MPa | 40~45 | D638 |
| Elongation at break | % | 300~400 | D638 |
| Impact Strength | kJ/m^2 | ≥140 | D250 |
| Rockwell Hardness | kJ/m^3 | 40~60 | D747 |
| Abrasion Loss | mg/1000 times | 70 | D1175 |
| Distortion Temperature | ºC | 85 | D648 |
Application Field
1. Lining: Silos, hoppers, wear-resistant plates, brackets, chute like reflux devices, sliding surface, roller, etc.
2. Food Machinery: Guard rail, star wheels, guide gear, roller wheels, bearing lining tile, etc.
3. Paper-making machine: Water lid plate, deflector plate, wiper plate, hydrofoils.
4. Chemical Engineering: Corrosion and wear-resistant mechanical parts
5. Other: Agricultural machinery, ship parts, electroplating industry, extreme low temperature mechanical components.
6. Thermal power: coal handling, storage of coal, coal bunker lining
7. Coal processing: sieve plate, filter, U-underground coal chute
8. Concrete: cement raw and finished product silo silo lining
9. Grain: food storage or chute lining
10. Mining: sieve plate, chute linings, wearproof anti-bonding part
11. Some kind of rubber fender panels and front face of rubber fender
12. Other fields include Ice rink, water tank etc.
As a new type of engineering plastic, UHMWPE sheet possesses multiple performance advantages:
Extraordinary wear-resistant,4~6 times higher than other plastic,6~9 times higher than steel, and 26 times higher than copper.
Highly impact strength, 10 times higher than PA6 and PP
Low friction coefficient (0.05~0.11), and capable of self lubrication
Unattractive to foreign material, and anti-sticking while sliding
Resistant to chemical corrosion
