Customize Radiation Shielding Products 5% 10% 15% Boronated UHMWPE Parts UHMWPE Sheet

3%-40% Boronated Ultra High Molecular Weight Polyethylene ( UHMWPE ) radiation shielding sheets are specially designed for nuclear shielding applications.

They are composed of 3%-40% Boron by weight, while the rest of the sheet is made of PE.
Availability:
Quantity:
  • Boron UHMWPE Parts
  • Xinxing
3%-40% Boronated Ultra High Molecular Weight Polyethylene ( UHMWPE ) radiation shielding sheets are specially designed for nuclear shielding applications. They are composed of 3%-40% Boron by weight, while the rest of the sheet is made of PE.

The Boron in these sheets shields against neutrons in a wide array of applications, including X-rays, nuclear submarines, cancer treatment facilities, nuclear power plants, seaports, airports, border protection, labs and other applications requiring attenuation of thermal neutrons.

At a lower cost and lighter weight than lead, UHMWPE radiation shielding sheets can be used to replace lead in nuclear shielding applications.


TECHNICAL SPECIFICATIONS


(based on 10% by weight borated PE sheet with thickness 15cm)
Density
≥1.028 g/cm3
Density contrast
≤0.01 g/cm3
Coefficient of linear expansion
8.933×10-51/℃
Heat resistance termperature
126℃ (DTA measure)
Compressive strength
≈24 MPa
Notch impact strength
≈19KJ/m2
Heat deflection temperature (load ρ=0.46Mρa)
72 ℃


FEATURES

1. Lighter weight and lower cost than lead
2. High effect of machine processing
3. Corrosion resistance
4. Odorless, non-toxic
5. High impact strength


THE SIZE OF SHEET WE MANUFACTURE

Size is fixed, but thickness can be customized from 6mm to 200mm. Contact me if you want thicker one.

LENGTH
(mm)
WIDTH
(mm)
THICKNESS
(mm)
Size 1
3000
1500
6-200
Size 2
3050
1220
6-200
Size 3
4700
1200
6-200
Size 4
5000
1300
6-200
Size 5
4500
2000
6-200
Size 6
2000
1000
6-200
Size 7
6000
1800
6-200
Size 8
3000
3000
6-200


CUSTOMIZATION SERVICE

Boron content
From 3% to 40% by weight
Thickness
6-200mm (contact me if you want thicker one)
Color
Black, white
Machine processing
Available
LOGO
Laser printing, Engraving or Labeling
Add other elements?
Available. (contact me for detail)
